Schneider KNX Push Button 8-Gang with Thermostat System M

Schneider KNX Push Button 8-Gang with Thermostat System M, White — MTN6214-0319

The Schneider Push Button 8-Gang joins the KNX bus and works inside a Schneider Electric KNX system. Because it speaks native KNX, it drops into any ETS project. So integrators add it without extra gateways. As a result, it combines eight operating rockers with a built-in room thermostat, and it keeps the whole install tidy.

Why choose this Push Button 8-Gang

First, it installs quickly and neatly on a System M frame. Then, it configures fully in ETS. Moreover, Schneider builds it for daily use in homes, offices and hotels. In short, it gives proven KNX performance. In addition, the thermostat controls heating and cooling right from the wall, so each room stays comfortable.

Key features

• Eight operating points (rockers)
• Integrated room temperature control
• Switch, dim, blind and scene functions
• Status LEDs on every rocker
• Flush System M design in white
• Bus powered, no extra supply needed

How this unit works

You assign each rocker a function in ETS. Then, one press sends a switch, dim, blind or scene command to the bus. Also, the thermostat reads the room and drives the heating or cooling valve. Therefore, one wall device covers both control and comfort. Furthermore, the status LEDs show the state of each load at a glance.

Where to use it

You can fit this Push Button 8-Gang unit in homes, hotels, offices and meeting rooms. Also, it pairs well with Schneider actuators, sensors and interfaces. Therefore, you build one coherent system from a single brand. Furthermore, it keeps wiring simple and service easy for the installer.

Specifications and setup

You configure the device in ETS. Also, it belongs to the wider Schneider KNX range at Infinitex. Thus, you can source a full system from one place.

• Brand: Schneider Electric
• Reference: MTN6214-0319
• Protocol: KNX (KNX-TP)
• Gangs: 8 with thermostat
• Mounting: Flush, System M
• Configuration: ETS

Infinitex supplies Schneider Electric KNX products in the UAE. Moreover, we offer project pricing and ETS support.

Compatibility

• Bus system: KNX twisted pair, to EN 50090 and ISO/IEC 14543-3.
• Configuration: ETS 5 or ETS 6. The manufacturer publishes the product database free of charge.
• Interoperable with KNX-certified devices from any manufacturer. ABB, Schneider, Siemens, Gira, Jung and Theben all sit on the same bus, so this unit works inside a mixed-brand installation.
• Bus supply: 21-30 V DC from a standard KNX power supply.
• Room temperature control: the setpoint and the measured value travel over the bus to KNX valve, fan-coil or underfloor heating actuators. No proprietary cabling.
• Not compatible with Zigbee, Z-Wave, Wi-Fi-only or Matter-only devices unless a KNX gateway is added.
