ABB Tenton KNX Room Controller 6-fold (RTC master) — SBR/U6.0.1

The ABB Tenton is a 3-in-1 KNX device: a room temperature controller combined with built-in temperature, humidity and CO2 (air-quality) sensors, plus 6 pushbutton operating points. It measures the indoor climate and controls heating, ventilation and fan-coil actuators — all from one flush-mounted control element with an integrated bus coupler and labelling field.

Room temperature control (master)

This is the master unit: it runs the room temperature controller logic and drives the HVAC/fan-coil actuators. Fan stages can be switched manually or in automatic mode, with base-load operation supported.

3-in-1 sensing

• Temperature sensor
• Humidity (moisture) sensor
• CO2 / air-quality sensor
• Class 1 temperature controller — contribution to space heating efficiency 1.0%

Push functions & colour concept

The 6 operating points handle switching, dimming, blinds, value sending and scenes. Tenton’s colour concept (yellow=lighting, blue=blind, orange=RTC, magenta=scene, white=neutral) makes each function readable at a glance.

Finishes

Available in Studio White, Aluminium Silver, Studio White Matt and Black Matt. Flush mounting into a European round or UK square box (with adapter).

Technical specifications at a glance

• Range: ABB Tenton
• Type: Room temperature controller (master) with CO2 & humidity sensor
• Protocol: KNX (KNX-TP), integrated bus coupler
• Operating points: 6-fold
• Sensors: temperature, humidity, CO2
• Installation: Flush mounted (European round / UK square with adapter)
• Protection: IP20
• Dimensions: 117.1 × 90.1 × 13.5 mm
• Operating temperature: −5 °C … +45 °C
• Configuration: ETS
