ABB JRA/S 4.230.1.1 KNX Blind/Shutter Actuator (4-Fold, 230V AC)

The ABB JRA/S 4.230.1.1 (2CDG110120R0011) offers a specialized solution for automating motorized window coverings. Primarily, ABB Blind/Shutter Actuator 4-fold 230V bridges the gap between the KNX bus and 230V AC motors. Consequently, it grants users total control over natural lighting and privacy in any smart building.
Key Features and Functional Benefits:
Technical ParameterSpecification / Feature
Brand & ManufacturingABB / Germany 🇩🇪
Protocol CompatibilityKNX Standard Certified
Channel Configuration4 Independent Outputs (4-Fold)
Output Load Voltage230 V AC (Ideal for standard tubular motors)
Form Factor / MountingDIN-Rail Mounted (MDRC)
Control Logic PowerDrawn directly from the KNX Bus line

Premium Functional Benefits for E-Commerce Platforms

High-Density Control with Built-In Motor Protection

By managing four independent output channels within a single compact module, this actuator reduces overall distribution board space and lowers per-channel installation costs. Each channel features an uncompromised mechanical and electronic interlock circuit. This safety mechanism physically prevents the simultaneous activation of UP and DOWN directional voltages. By eliminating overlapping commands, the actuator completely eliminates the risk of phase-to-phase short circuits, safeguarding expensive motorized blinds from permanent electrical damage.

Advanced Meteorological Defense and Safety Overrides

This intelligent device functions as an active property safeguard when linked to a central KNX Weather Station. It continuously processes environmental data to execute high-priority protective actions:
  • Wind & Storm Protection: Instantly forces outdoor drapes and fragile awnings to retract during hazardous wind gusts.
  • Rain & Frost Defense: Disables shutter movement during freezing temperatures to prevent motorized gearboxes from tearing against ice build-up.
  • Forced Operation Logic: Emergency commands (such as fire alarms or structural maintenance overrides) instantly bypass local room switches to guarantee building safety.

Dynamic Solar Tracking & HVAC Energy Optimization

The ABB JRA/S 4.230.1.1 is heavily utilized to achieve green building certifications (such as LEED or BREEAM). By executing ultra-precise slat angle adjustments based on the real-time position of the sun, the device blocks harsh solar radiation from entering the building interior. This drastically lowers the solar heat gain coefficient (SHGC) of the glass facades, which minimizes the thermal cooling load placed on HVAC chillers and air conditioning systems. The result is a total building energy consumption reduction of up to 30%.

Luxury Scene Automation & Precision Positioning

Through detailed parameterization in the ETS software, users can enjoy smooth, automated daily routines:
  • Morning Wake-Up: Blinds across the entire facade quietly open to exactly 25% at sunrise.
  • Security Closed Mode: All four channels deploy shutters completely at nightfall to enhance privacy and deter intruders.
  • Presentation / Cinema Scene: Meeting room shades descend to 100% while internal lighting dims via a single button press.

Why Engineering Teams Specify ABB JRA/S Actuators

Built with premium German components, the ABB JRA/S series delivers unrivaled durability, eliminating frequent maintenance calls and system downtime. It is the gold standard for architects, developers, and smart home specialists worldwide.
